Deye Single Phase Hybrid Inverter SUN-8K-SG05LP1-EU-SM2
- Category: Deye Hybrid Inverter
- Features
Product Parameter
| Parameter | Specification |
|---|---|
| Model | SUN-8K-SG05LP1-EU-SM2 |
| Rated Power | 8kW |
| Phase | Single Phase |
| Battery Type | Lithium-ion / Lead-acid |
| Battery Voltage Range | 40-60V |
| Max Charging Current | 190A |
| Max Discharging Current | 190A |
| Max PV Input Power | 16,000W |
| Max PV Voltage | 500V |
| MPPT Number | Dual MPPT |
| Parallel Capability | Up to 16 Units |
| Max Efficiency | 97.6% |
| Protection Degree | IP65 |
| Cooling Method | Intelligent Air Cooling |
| Noise Level | <30dB |
| Dimension (W×H×D) | 366 × 589.5 × 237mm |
| Weight | Weight |
Product Description
Deye SUN-8K-SG05LP1-EU-SM2 Hybrid Inverter
8kW Single Phase Low Voltage Hybrid Solar Inverter
High Efficiency | Flexible Energy Storage | Intelligent Energy Management
The Deye SUN-8K-SG05LP1-EU-SM2 is an advanced 8kW single-phase hybrid inverter designed for residential and small commercial solar energy systems. Supporting both on-grid and off-grid operation, it integrates solar power generation, battery storage, grid connection, and backup power management into one intelligent energy solution.
With low-voltage battery compatibility, dual MPPT technology, 190A charging and discharging capability, and parallel expansion support, this hybrid inverter provides reliable energy independence while maximizing solar utilization.
Product Overview
The Deye SUN-8K-SG05LP1-EU-SM2 hybrid inverter enables homeowners and businesses to achieve greater energy independence by efficiently managing power from multiple sources.
The inverter can intelligently switch between:
Solar PV generation
Battery energy storage
Grid power
Diesel generator input
During normal operation, solar energy can be prioritized for household consumption, while excess electricity can be stored in batteries for later use. In the event of grid interruption, the system can provide backup power to maintain essential loads.
With a rated output power of 8kW and support for 16kW PV input, this inverter is suitable for high-demand residential systems and small-scale commercial applications.
Key Features
1. High Power Output with Flexible Solar Input
Rated Output Power: 8kW
Maximum PV Input Power: 16kW
Maximum PV Voltage: 500V
Dual MPPT Trackers
2. Advanced Battery Energy Storage Compatibility
Battery Specifications:
Battery Voltage Range: 40-60V
Maximum Charging Current: 190A
Maximum Discharging Current: 190A
Battery Type: Lithium-ion / Lead-acid
3. Reliable Backup Power Capability
Seamless backup power supply
Supports high starting power loads
Maximum off-grid peak power: 16kW for 10 seconds
4. Expandable System Design
Supports up to 16 units parallel connection
Compatible with multiple battery configurations
Suitable for system expansion
5. Intelligent Monitoring & Energy Management
RS485
CAN
RS232
WiFi (optional)
LAN (optional)
Bluetooth (optional)
4G monitoring (optional)
Application Scenarios
Residential Solar Storage：Villas,Houses,Residential communities
Small Commercial Solar Systems:Offices,Retail stores,Small factories
Remote & Off-grid Applications:Remote homes,Farms,Rural projects
Safety & Protection Features
Reverse polarity protection
Over-voltage protection
Short circuit protection
Surge protection
Ground fault detection
Over-temperature protection
IP65 outdoor protection rating
FAQ:
Q1: Is the Deye SUN-8K-SG05LP1-EU-SM2 suitable for residential use?
Yes. This inverter is designed for residential solar-plus-storage systems and can provide both energy optimization and backup power functions.
Q2: Can this inverter work without batteries?
Yes. It can operate in grid-connected solar applications, while adding batteries enables energy storage and backup functions.
Q3: What battery voltage does this inverter support?
The inverter supports low-voltage batteries with a voltage range of 40-60V.
Q4: Can multiple Deye SUN-8K-SG05LP1-EU-SM2 units work together?
Yes. Up to 16 inverter units can be connected in parallel for larger energy systems.
