Product Description

Deye SUN-7/7.6/8/10/12K-SG06LP1-EU-BM3 Hybrid Inverter

The Deye SUN-7/7.6/8/10/12K-SG06LP1-EU-BM3 is a single-phase low voltage hybrid inverter designed for residential and small commercial energy storage applications. With 7kW to 12kW power options, it integrates solar power generation, battery storage, grid connection, and backup power management into one intelligent energy solution.

Supporting low voltage batteries (40–60V) and advanced battery management, this hybrid inverter enables efficient energy storage and flexible power control. It features 3 MPPT trackers, high PV input capacity, AC coupling capability, and parallel operation support, providing reliable energy independence and optimized solar utilization.

Product Features

High Efficiency Solar Conversion

• Supports 7kW, 7.6kW, 8kW, 10kW, and 12kW output power models.
• Up to 3 MPPT trackers for improved solar energy harvesting.
• Supports high PV input power for different rooftop solar configurations.

Low Voltage Battery Compatibility

• Compatible with lead-acid and lithium-ion batteries.
• Supports 40–60V low voltage battery systems.
• Maximum charging and discharging current up to 250A for the 12kW model.

Flexible Energy Management

• Supports multiple operation modes including self-consumption, battery backup, and grid interaction.
• Six time periods for intelligent battery charging and discharging scheduling.
• Supports storing energy from diesel generators for enhanced energy flexibility.

Reliable Backup Power

• Provides stable off-grid power supply during grid outages.
• Supports parallel connection for expanding system capacity.
• Designed for residential energy independence and emergency backup applications.

Smart and Durable Design

• Colorful touch LCD display for easy operation.
• IP65 protection rating suitable for indoor and outdoor installation.
• Supports remote monitoring and intelligent system management.

Technical Specifications
