Deye SUN-8-12K-SG06LP1-EU-CM3 Hybrid Solar Inverter
- Category: Deye Hybrid Inverter
- Features
Product Description
Deye SUN-8-12K-SG06LP1-EU-CM3 Hybrid Solar Inverter
The Deye SUN-8/10/12K-SG06LP1-EU-CM3 is a single-phase low-voltage hybrid solar inverter designed for residential solar energy storage systems. Available in 8kW, 10kW, and 12kW models, it integrates solar power generation, battery storage, grid connection, and backup power management in one flexible solution.
Compatible with 40–60V lead-acid and lithium-ion batteries, this Deye hybrid inverter supports up to 16 units in parallel for on-grid and off-grid applications. Its three MPPT trackers provide flexible PV system design, while AC coupling allows integration with existing solar installations.
With programmable battery charging and discharging, diesel generator integration, and a maximum efficiency of 97.6%, the SUN-SG06LP1-EU-CM3 series is suitable for residential solar battery storage, self-consumption optimization, and flexible energy management.
Key Features
8kW, 10kW & 12kW Power Options: Choose the output capacity to match different residential solar energy storage requirements.
Three MPPT Trackers: Supports flexible solar panel string configurations and efficient PV energy harvesting.
Low-Voltage Battery Compatibility: Works with compatible 40–60V lead-acid or lithium-ion batteries.
High Battery Charging and Discharging Current: Supports up to 185A for the 8kW model, 220A for the 10kW model, and 250A for the 12kW model.
High PV Input Capacity: Supports up to 16kW, 20kW, and 24kW maximum PV access power for the 8kW, 10kW, and 12kW models, respectively.
On-Grid and Off-Grid Operation: Supports parallel operation of up to 16 units, subject to system design and installation requirements.
AC Coupling: Enables integration with compatible existing solar power systems.
Flexible Energy Management: Supports six programmable battery charging and discharging time periods.
Diesel Generator Integration: Supports energy storage from a compatible diesel generator.
High Efficiency and Protection: Offers up to 97.6% maximum efficiency, IP65 ingress protection, and intelligent air cooling.
Specifications
General Information
Specification | Details |
|---|---|
Brand | Deye |
Product Type | Single-Phase Low-Voltage Hybrid Solar Inverter |
Model Series | SUN-SG06LP1-EU-CM3 |
Available Models | SUN-8K / SUN-10K / SUN-12K-SG06LP1-EU-CM3 |
Rated AC Output Power | 8,000W / 10,000W / 12,000W |
Battery Type | Lead-acid or Lithium-ion |
Battery Voltage Range | 40–60V |
Number of MPPT Trackers | 3 |
Maximum Efficiency | 97.6% |
Protection Rating | IP65 |
Cooling Method | Intelligent air cooling |
Display | LCD |
Communication Interfaces | Wi-Fi, RS485, CAN |
Dimensions (W × H × D) | 340 × 580 × 234mm, excluding connectors and brackets |
Weight | Approx. 24.6–24.9kg, depending on model |
Warranty | 5 years / up to 10 years, subject to installation country and warranty policy |
Battery Input Specifications
Specification | 8kW | 10kW | 12kW |
|---|---|---|---|
Battery Voltage Range | 40–60V | 40–60V | 40–60V |
Max. Charging Current | 185A | 220A | 250A |
Max. Discharging Current | 185A | 220A | 250A |
Number of Battery Inputs | 1 | 1 | 1 |
Lithium Battery Management | Self-adaptation to BMS | Self-adaptation to BMS | Self-adaptation to BMS |
PV Input Specifications
Specification | 8kW | 10kW | 12kW |
|---|---|---|---|
Maximum PV Access Power | 16,000W | 20,000W | 24,000W |
Maximum DC Input Power | 12,800W | 16,000W | 19,200W |
Maximum DC Input Voltage | 500V | 500V | 500V |
Start-up Voltage | 125V | 125V | 125V |
MPPT Voltage Range | 150–425V | 150–425V | 150–425V |
Rated PV Input Voltage | 370V | 370V | 370V |
Number of MPPT Trackers | 3 | 3 | 3 |
AC Input / Output Specifications
Specification | 8kW | 10kW | 12kW |
|---|---|---|---|
Rated AC Active Power | 8,000W | 10,000W | 12,000W |
Maximum AC Apparent Power | 8,800VA | 11,000VA | 13,200VA |
Rated AC Input/Output Current | 36.4A / 34.8A | 45.5A / 43.5A | 54.6A / 52.2A |
Maximum AC Input/Output Current | 40A / 38.3A | 50A / 47.9A | 60A / 57.4A |
Rated AC Voltage | 220/230V | 220/230V | 220/230V |
Grid Frequency | 50/60Hz | 50/60Hz | 50/60Hz |
Peak Off-Grid Power | 2 × rated power for 10 seconds | 2 × rated power for 10 seconds | 2 × rated power for 10 seconds |
Power Factor Adjustment Range | 0.8 leading to 0.8 lagging | 0.8 leading to 0.8 lagging | 0.8 leading to 0.8 lagging |
Maximum Continuous AC Passthrough | 65A | 70A | 70A |
Efficiency, Protection & Operating Conditions
Specification | Details |
|---|---|
Maximum Efficiency | 97.6% |
Euro Efficiency | 96.5% |
MPPT Efficiency | Greater than 99% |
Total Current Harmonic Distortion (THDi) | Less than 3% of nominal power |
DC Injection Current | Less than 0.5% of rated current |
Surge Protection | Type II DC and Type II AC |
Integrated Protection | DC reverse polarity, AC overcurrent, overvoltage, short circuit, thermal protection, anti-islanding and residual current detection |
Arc Fault Circuit Interrupter (AFCI) | Optional |
Operating Temperature | −40°C to +60°C, with derating above 45°C |
Relative Humidity | 0–100% |
Maximum Operating Altitude | 3,000m |
Noise Level | Less than 45dB |
Inverter Topology | Non-isolated solar input; isolated battery |
Parallel Operation | Up to 16 units for on-grid and off-grid operation, subject to system requirements |
Frequently Asked Questions
1. What is the Deye SUN-8/10/12K-SG06LP1-EU-CM3 hybrid inverter?
The Deye SUN-SG06LP1-EU-CM3 is a single-phase low-voltage hybrid solar inverter available in 8kW, 10kW, and 12kW models. It integrates solar PV generation, battery storage, and grid-connected or off-grid energy management.
2. Which batteries are compatible with the Deye SUN-SG06LP1-EU-CM3?
The inverter supports compatible 40–60V lead-acid and lithium-ion batteries. Lithium battery operation supports automatic adaptation to the battery management system (BMS). Battery compatibility should be confirmed before installation.
3. How many solar panels can the Deye 8kW, 10kW, and 12kW inverter support?
The maximum PV access power is 16kW for the 8kW model, 20kW for the 10kW model, and 24kW for the 12kW model. The actual number of solar panels depends on panel wattage, string design, voltage, and current limits.
4. Does the Deye SUN-SG06LP1-EU-CM3 support off-grid operation?
Yes. The inverter supports off-grid operation and can deliver peak power up to twice its rated power for 10 seconds. Actual backup capability depends on load requirements, battery capacity, and system configuration.
5. Can multiple Deye SUN-SG06LP1-EU-CM3 inverters operate in parallel?
Yes. Up to 16 units can operate in parallel for on-grid and off-grid applications, subject to the manufacturer's installation requirements and system design.
6. Can this Deye hybrid inverter be connected to an existing solar system?
Yes. The inverter supports AC coupling, making it suitable for retrofitting compatible existing solar installations. A qualified installer should verify system compatibility before installation.
7. What is the maximum efficiency of the Deye SUN-SG06LP1-EU-CM3?
The series offers a maximum efficiency of 97.6%, with a Euro efficiency of 96.5% and MPPT efficiency greater than 99%, according to the manufacturer's specifications.
8. Is the Deye SUN-SG06LP1-EU-CM3 suitable for residential solar energy storage?
Yes. Its single-phase output, low-voltage battery compatibility, programmable charging and discharging, and flexible system expansion make it suitable for residential solar energy storage applications.
