INVT LDW-1 DIN-Rail Logger
The INVT LDW-1 DIN-Rail Logger is a solar monitoring data logger designed to collect operating data and power generation information from PV inverters, meters, and other compatible devices. Supporting RS485, RS422, and RS232 interfaces, it enables communication with multiple devices and uploads data to a remote monitoring platform via Wi-Fi or Ethernet.
With support for connecting 1–10 devices, configurable data upload intervals, and remote monitoring capabilities, the LDW-1 helps solar installers and system operators monitor PV system performance, analyze historical data, and improve operation and maintenance efficiency. Its compact design and standard 35 mm DIN-rail mounting make it suitable for solar monitoring installations.
Key Features of INVT LDW-1 DIN-Rail Logger
35 mm DIN-Rail Mounting: Standard DIN-rail installation for convenient integration into compatible electrical cabinets.
Multi-Device Communication: Supports RS485, RS422, and RS232 interfaces for connecting compatible inverters, meters, and other devices.
Wi-Fi and Ethernet Connectivity: Transfers collected PV system data to a remote monitoring platform.
Data Resumption: Helps maintain data integrity when communication is interrupted.
Remote Upgrade and Debugging: Supports remote maintenance to simplify system troubleshooting and operation.
Real-Time Alerts: Provides alert notifications to help operators identify faults and respond promptly.
Configurable Data Upload: Supports adjustable data uploading intervals to meet different monitoring requirements.
Compact Design: Space-saving construction for convenient installation in solar monitoring systems.
Specifications
Specification | Details |
|---|---|
Product Model | LDW-1 |
Product Type | DIN-Rail Solar Data Logger |
Remote Communication Interface | Wi-Fi |
Wi-Fi Frequency | 2.412–2.484 GHz* |
Ethernet Interface | 10/100 Mbps, adaptive |
Number of Connections | 1–10 devices |
Local Communication Interfaces | RS485 / RS422 / RS232 |
Working Voltage | DC 4.7–15 V |
Working Power | 1 W |
Serial Communication Rate | 1,200–115,200 bps, configurable |
Data Uploading Interval | Default: 5 minutes; configurable from 1–15 minutes |
Memory | 2 MB Flash; 512 KB–16 MB optional |
User Configuration | AT instruction set / remote server |
SIM Card | Not required for the Wi-Fi configuration |
Working Temperature | -40°C to +85°C |
Working Humidity | Below 90%, non-condensing |
Dimensions (W × H × D) | 76 × 91 × 18 mm |
Installation Method | 35 mm DIN rail |
Additional Functional Specifications
Item | Description |
|---|---|
Data Collection | Operating status and power generation data from compatible inverters, meters, and devices |
Remote Monitoring | Supported through a compatible monitoring platform |
Historical Data | Graphical display of historical operating data through the monitoring platform |
Data Integrity | Data resumption function |
Maintenance | Remote upgrade and system debugging |
Alerts | Real-time alert notifications |
Installation Environment | Compatible electrical cabinets and PV monitoring installations |
Typical Application | Residential, commercial, and distributed PV monitoring systems |
