Product Description

JA Solar JAM72D10 390-410W Bifacial Double Glass Half Cell Solar Panel

The JA Solar JAM72D10 390-410W Bifacial Double Glass Solar Module is a high-performance photovoltaic panel designed for utility-scale solar projects, commercial PV systems, and distributed energy applications. Built with MBB (Multi Busbar) mono PERC cells and half-cell technology, this module delivers higher energy output, improved reliability, and enhanced power generation performance under different environmental conditions.

Featuring a double glass bifacial structure, the JAM72D10 series can generate electricity from both the front and rear sides of the module by capturing reflected sunlight. Compared with traditional single-sided modules, the bifacial design improves overall energy yield, especially when installed on reflective surfaces such as white roofs, concrete areas, and ground-mounted solar farms.

With a power range of 390W to 410W, module efficiency up to 20.0%, and excellent temperature performance, JA Solar JAM72D10 solar panels provide stable long-term operation in demanding environments. The glass-glass structure enhances mechanical strength, moisture resistance, and durability, making it suitable for projects requiring high reliability and extended service life.

Product Features

1. High Efficiency MBB Mono PERC Technology

The JAM72D10 module adopts advanced Multi Busbar (MBB) mono PERC cell technology, improving current collection efficiency and reducing electrical losses.

Key advantages:

• Power output from 390W to 410W
• Module efficiency up to 20.0%
• Improved light utilization capability
• Reduced internal resistance losses
• Better energy generation performance

2. Bifacial Double Glass Design for Higher Energy Yield

The double glass structure enables the module to absorb sunlight from both front and rear surfaces.

Benefits:

• Additional rear-side power generation
• Higher total system energy output
• Improved performance in reflective environments
• Enhanced resistance against humidity and harsh weather

The JAM72D10 series supports backside power gain up to 25%, allowing rated power output to increase depending on installation conditions.

3. Half-cell Technology for Better Performance

The half-cell design reduces current transmission losses and improves module reliability.

Advantages:

• Lower operating current
• Reduced hot spot risk
• Better shading tolerance
• Improved power output in real-world conditions

4. Durable Double Glass Structure

The glass-glass module design provides superior mechanical stability compared with traditional backsheet modules.

Features:

• 2.0mm front glass + 2.0mm rear glass
• Better resistance against moisture penetration
• Improved PID resistance
• Longer operational lifespan

5. Designed for Large-Scale PV Applications

With a 1500V DC system design and strong mechanical performance, JAM72D10 modules are optimized for:

• Utility-scale solar farms
• Commercial rooftop systems
• Industrial photovoltaic projects
• Solar carports
• Ground-mounted PV installations

Technical Specifications

Electrical Characteristics (STC)

Bifacial Power Gain Performance
(Reference: JAM72D10-390 Front Side Output)

Mechanical Characteristics

Operating Conditions
