Product Description

Jinko Tiger N-Type 60HL4-(B) 475-500W Solar Panel

Jinko Tiger Neo N‑Type 60HL4‑(B) is a high‑performance mono‑facial solar module built with advanced N‑type TOPCon cell technology, covering power output from 475 W to 500 W with module efficiency reaching up to 23.17%. Adopting 120‑piece half‑cut cell design together with SMBB multi‑busbar technology, this panel delivers superior power generation performance, lower light‑induced degradation (LID/LeTID) and excellent low‑light response compared with conventional P‑type modules.

Measuring 1906×1134×30 mm with 22.5 kg weight, it is compact and easy for transportation and on‑site installationJinkoSolar. Engineered for residential, commercial and industrial rooftop & ground‑mount solar projects, the module features robust mechanical construction and complete international certification, supported by JinkoSolar’s reliable 12‑year product warranty and 30‑year linear power performance warranty to secure long‑term return on investment. Positive power tolerance 0~+3% guarantees actual output often exceeds nominal rated power.

Product Features

Advanced N‑type TOPCon & HOT 3.0 Technology

N‑type tunnel oxide passivating contact cell technology greatly reduces LID & LeTID degradation. HOT 3.0 process further improves conversion efficiency and operational reliability, achieving stable power output even under high‑temperature working environments.

SMBB Multi‑busbar Half‑cell Design

Optimized busbar layout enhances light‑trapping effect and electric‑current collection capability. Half‑cut cell structure lowers internal power loss, lifting actual power yield and module long‑term reliability.

Excellent Anti‑PID Performance

Optimized cell manufacturing workflow and strict raw‑material control effectively suppress PID‑related power attenuation, keeping high power retention throughout service life.

Superb Environmental Adaptability

Certified for high salt‑mist and ammonia corrosion resistance, suitable for coastal and heavy‑industrial regions. Tempered anti‑reflection low‑iron 3.2 mm front glass plus anodized aluminum frame ensure weather resistance.

High Mechanical Loading Capacity
Passed strict mechanical test: withstands 5400 Pa front snow load and 2400 Pa rear wind load, adapts to complicated outdoor weather conditions. IP68‑rated junction box provides solid dust‑proof and waterproof protection.

Outstanding Long‑term Warranty & Degradation Performance

1‑percent power degradation in the first year; merely 0.40% annual linear degradation within following 29 years. 12‑year product workmanship warranty and 30‑year linear‑power warranty deliver solid investment protection.

Full‑set Global Certifications

Compliant with IEC61215:2021, IEC61730:2023, anti‑salt‑mist / anti‑ammonia / anti‑PID related IEC standards; ISO9001, ISO14001, ISO45001 system certifications, meets worldwide market access requirements.

Wide Application Compatibility

Power range 475‑500 W, max system voltage 1500 V. Perfect fit for household rooftop, C&I distributed solar systems as well as small‑scale ground‑mount PV plants

SPECIFICATIONS

Mechanical Characteristics

Packaging Configuration

Specifications (STC)

STC: Irradiance 1000W/m², Cell Temperature 25℃, AM=1.5

Application Conditions
