Solis S6-EH2P(9.6-16)K03-NV-YD-L Single Phase Hybrid Low Voltage Inverter

  • Category: Solis Hybrid Inverter
  • Features
    • Solis S6-EH2P(9.6-16)K03-SV-YD-L-US is a 48V split-phase hybrid inverter delivering 9.6-16kW power for whole-home backup and energy storage applications. With 200A pass-through, high PV input capability, <10ms backup switching, and flexible battery compatibility, it provides a reliable and scalable solar energy solution for North American homes.

Product Description

Solis S6-EH2P(9.6-16)K03-SV-YD-L-US

48V Split Phase Hybrid Energy Storage Inverter

The Solis S6-EH2P(9.6-16)K03-SV-YD-L-US is a powerful 48V low-voltage split-phase hybrid inverter designed for North American residential energy storage applications.

With flexible power options from 9.6kW to 16kW, this inverter supports on-grid, off-grid, and microgrid operation, providing homeowners with reliable energy independence and whole-home backup capability.

Featuring high PV input capability, a built-in 200A bypass and pass-through function, intelligent generator integration, and compatibility with various battery systems, the S6-EH2P series delivers a flexible and cost-effective solar-plus-storage solution.

Key Features

Flexible Hybrid Energy Operation

  • Supports 48V hybrid operation with on-grid, off-grid, and microgrid capabilities
  • Enables flexible energy management for residential and backup power applications

Flexible System Integration

  • Equipped with a smart port supporting versatile configurations, including:

AC coupling
Generator integration

  • Provides greater system flexibility for different installation scenarios

High PV Input Capability

  • Supports 20A high PV input current, compatible with larger and higher-power PV modules
  • Improves system power density while reducing energy loss caused by module clipping

Integrated Backup Power Solution

  • Built-in 200A pass-through and bypass function
  • Reduces the need for additional external hardware
  • Simplifies installation, lowers system costs, and creates a more compact energy storage solution

Enhanced Battery Energy Utilization

  • Supports up to 290A battery charge/discharge current
  • Enables higher energy storage capacity from excess solar generation
  • Improves overall system efficiency and maximizes solar energy utilization

Technical Specifications

Models 9.6K 11.4K 12K 14K 16K
Input DC (PV side)
Recommended max. PV power 15.36 kW 18.24 kW 19.2 kW 22.4 kW 25.6 kW
Max. input voltage 550 V
Rated voltage 380 V
Start-up voltage 100 V
MPPT voltage range 160-450 V 100-450 V 100-450 V 100-450 V 186-450 V
Fullload MPPT voltage range 160-450 V 100-450 V 100-450 V 100-450 V 186-450 V
Max. input current per MPPT 40 A
Max. short circuit current per MPPT 50 A
Number of MPPTs / Number of strings per MPPT 1.50
Battery
Battery type Li-ion/Lead-acid
Battery voltage range 40 - 60 V
Max. charge/discharge current 200 A 237.5 A 250 A 250 A 290 A
Communication CAN / RS485
Number of batteries per inverter See Battery Compatibility Sheet
Output AC (Grid side)
Rated output power 9.6 kW 11.4 kW 12 kW 14 kW 16 kW
Max. apparent output power 9.6 kVA 11.4 kVA 12 kVA 14 kVA 16 kVA
Rated output voltage 240 V
Rated frequency 60 Hz
Rated grid output current 40 A 47.5 A 50 A 58.3 A 66.7 A
Max. output current 40 A 47.5 A 50 A 58.3 A 66.7 A
Max. output current clipping 120 A 142.5 A 150 A 174.9 A 200.1 A
THDi < 3%
Input AC (Grid side)
Input voltage range 211 - 264 V
Max. input current 200 A
Frequency range 58.8 - 61.2 Hz
Output AC (Backup and Off-grid)
Rated output power 9.6 kW 11.4 kW 12 kW 14 kW 16 kW
Max. apparent output power 3×the rated power for 1 second & 2×therated power for 10 seconds
Backup switch time < 10 ms
Phase power L1/L2/N(PE), 120V / 240 V (split phase)
Rated output voltage(L1-L2) 240 V
AC output voltage range 211 - 264 V
Rated frequency 60 Hz
Rated output current 40 A 47.5 A 50 A 58.3 A 66.7 A
Max. output current protection,10 sec 80 A 95 A 100 A 116.7 A 133.3 A
Max. continuous AC pass through current 200 A
Max. allowable phase imbalance 50%
Backup support configurations Dedicated loads leading and whole-home
Power factor >0.99 (0.8 leading - 0.8 lagging)
THDv (@linear load) <3%
Input Generator
Max. input power 24 kW
Max. input current 100 A
Rated input frequency 60 Hz
Efficiency
Max. efficiency 96.02%
CEC efficiency 95.45%
Battery charged by PV max.efficiency 96.21%
Battery charged/discharged to AC max.efficiency 94.16%/94.22%
Protection
Ground fault monitoring Yes
Integrated AFCI Yes (PV only)
DC reverse-polarity protection Yes
Rapid shutdown NEC 2017 Integrated SunSpec-certified Transmitter
Compatible RSD receivers See MLPSD compatibility Sheet
Protection class / Over voltage category I / II
General Data
Dimensions (W × H × D) 21.02 × 36.61 × 11.69 in (534 × 930 × 297 mm)
Weight 145.06 lbs (65.8 kg)
Inverter topology Non-isolated (PV), Isolated (Battery)
Operating ambient temperature range -13°F to 140°F (-25℃ to 60℃)
Ingress protection TYPE 4X
Self-consumption (night) <85 W
Noise emission (typical) <65 dB
Cooling concept Intelligent fan-cooling
Relative humidity 0 - 100%
Mounting type Wall Bracket
Max. operation altitude 13120 ft (4000 m)
Safety Certifications UL 1741 PVRSS, UL 1699B, UL 1741, UL 1741 SB, CSAC22.2107.1-1
Grid Certifications IEEE 1547-2018,IEEE1547.1-2020,CA Rule21, SRD 20, Puerto Rico LUMA, Hawaii HECO
Emissions FCC Part 15 Class B
Features
DC connection Terminal Block (PV port) / Terminal Block (BAT port)
AC connection Terminal Block
Interface 7.0" LCD display & Bluetooth + APP
Revenue grade meter Optional
Monitoring platform SolisCloud (modbus map and API sharing available upon request)
Communication RS485, Optional:Cellular,Wi-Fi, LAN
